SELECTION DRAWING
Stainless Steel Braided Water Supply Hose — dimension key
L: assembly length; D: hose envelope; A/B: end interfaces; R: minimum installed bend radius. Selection schematic; not a production drawing.
PRODUCT REFERENCE · 1601822585525
Stainless Steel Braided Water Supply Hose
A braided hose assembly connects fluid interfaces through a flexible section. The internal liner, external braid and both end connections determine suitability; electrical conduit specifications do not apply.
Request a quotationSelection schematic, not a product photograph. Final appearance and configuration require an approved drawing or sample.
PRODUCT INTRODUCTION
Stainless Steel Braided Water Supply Hose
A braided hose assembly connects fluid interfaces through a flexible section. The internal liner, external braid and both end connections determine suitability; electrical conduit specifications do not apply.
This product reference
This reference is offered as stainless steel braided water supply hose. Specify the required size and configuration in the enquiry; dimensions and construction are confirmed against the selected item.
Applications
Water-supply connections after confirming medium, temperature and assembly requirements.
Selection & installation
Specify liner and braid materials, end A/end B threads, sealing seats, hose length and required pressure testing.
Technical confirmation
Confirm the exact material, dimensions, tolerances, installation conditions and required test documentation with your quotation. Store listing titles are not substitutes for approved product data sheets.
