SELECTION DRAWING
PE Heat Shrinkable Cable Protection Kit — dimension key
D/d: expanded/recovered bore; L1/L2/L3: specified cut lengths; t: recovered wall. Selection schematic; not a production drawing.
PRODUCT REFERENCE · 1601947980485
PE Heat Shrinkable Cable Protection Kit
A sleeve kit groups selected heat-shrink diameters and cut lengths for assembly or maintenance. Define the kit contents explicitly so each cable or connection receives the appropriate size.
Request a quotationProduct illustration based on a supplied product-family reference. Confirm the selected dimensions and end details by drawing or sample.
PRODUCT INTRODUCTION
PE Heat Shrinkable Cable Protection Kit
A sleeve kit groups selected heat-shrink diameters and cut lengths for assembly or maintenance. Define the kit contents explicitly so each cable or connection receives the appropriate size.
This product reference
This reference is offered as pe heat shrinkable cable protection kit. Specify the required size and configuration in the enquiry; dimensions and construction are confirmed against the selected item.
Applications
Harness assembly, workshop servicing and organized electrical maintenance.
Selection & installation
Provide the size list, quantity per size, cut length, colours and lining requirements. Confirm the material and rating of every kit component.
Technical confirmation
Confirm the exact material, dimensions, tolerances, installation conditions and required test documentation with your quotation. Store listing titles are not substitutes for approved product data sheets.
