Ribbed Hose for Ventilation and Dust Collection — dimension key
D: connection diameter; p: rib pitch; L: installed length; R: bend radius. Selection schematic; not a production drawing.
PRODUCT REFERENCE · 1601955241136
Ribbed Hose for Ventilation and Dust Collection
A ribbed duct carries air or collected material through a flexible route. The wall and reinforcement must be selected for the actual process rather than only the nominal diameter.
Request a quotationProduct illustration based on a supplied product-family reference. Confirm the selected dimensions and end details by drawing or sample.
PRODUCT INTRODUCTION
Ribbed Hose for Ventilation and Dust Collection
A ribbed duct carries air or collected material through a flexible route. The wall and reinforcement must be selected for the actual process rather than only the nominal diameter.
This product reference
This reference is offered as ribbed hose for ventilation and dust collection. Specify the required size and configuration in the enquiry; dimensions and construction are confirmed against the selected item.
Applications
Ventilation and dust-collection connections, subject to material and process review.
Selection & installation
Specify diameter, length, reinforcement, conveyed particles, airflow conditions and temperature. Assess static-control requirements where relevant.
Technical confirmation
Confirm the exact material, dimensions, tolerances, installation conditions and required test documentation with your quotation. Store listing titles are not substitutes for approved product data sheets.
