D1: relaxed diameter; D2: expanded diameter; L1/L2: corresponding lengths. Selection schematic; not a production drawing.
PRODUCT REFERENCE · 1601951494038
Expandable Nylon Braided Cable Sleeve
An expandable braided sleeve opens to pass over cable components and then conforms around the bundle. Installed length changes with expansion, so cut length needs allowance.
Request a quotationProduct illustration based on a supplied product-family reference. Confirm the selected dimensions and end details by drawing or sample.
PRODUCT INTRODUCTION
Expandable Nylon Braided Cable Sleeve
An expandable braided sleeve opens to pass over cable components and then conforms around the bundle. Installed length changes with expansion, so cut length needs allowance.
This product reference
This reference is offered as expandable nylon braided cable sleeve. Specify the required size and configuration in the enquiry; dimensions and construction are confirmed against the selected item.
Applications
Cable-bundle organization and abrasion protection appropriate to the selected braid material.
Selection & installation
Confirm polymer, nominal and expanded diameters, coverage, end finishing and length in the intended expanded state.
Technical confirmation
Confirm the exact material, dimensions, tolerances, installation conditions and required test documentation with your quotation. Store listing titles are not substitutes for approved product data sheets.
